Ti:Sapphire Laser Overview

Ti:Sapphire lasers have become prominent in the field of ultrafast lasers and oscillators due to their broad emission bandwidth and the ability to minimize opto-thermal effects over a wide range of operating parameters.  This article examines the construction of a high-power Ti:Sapphire laser from the ground up.  Mode-locked lasers are discussed, as are single-pass, multi-pass, and regenerative amplifiers.  The use of pulse pickers to help generate higher pulse energies is also discussed.

In order to build high-average-power Ti:Sapphire lasers, high-quality high-average-power green pump lasers are required as pumps for the final amplification stage.  This article examines the main requirements on the pump lasers, and also discusses the relative merits of Nd:YAG and Nd:YLF systems.

Continue reading

200W_pumplaser 684x244

Pump Lasers for Ultrafast Amplifiers

Ti:sapphire lasers have become prominent in the field of ultrafast lasers and oscillators due to their broad emission bandwidth and the ability to minimize opto-thermal effects over a wide range of operating parameters. In order to build high-average-power Ti:sapphire lasers, high-quality high-average-power green pump lasers are required.

Cutting Edge Optronics (CEO) offers the Patara-HP family of Q-switched green lasers, which are ideally suited as pump sources for pulsed Ti:sapphire amplifiers. The performance of the Patara-HP pump lasers is examined in this work, particularly the 100W and 200W average power systems. An analysis of pulse energies at varying repetition rates, beam quality and stability, pulse-to-pulse stability, long-term power stability and beam pointing stability is presented. A discussion of laser system reliability is also included.

Continue reading

HDS laser diode packaging increases power density by 2.5X

983x300 diodes dime1

Northrop Grumman Cutting Edge Optronics has developed a laser diode array package with  minimal bar-to-bar spacing. These High Density Stack (HDS) packages allow for a power density increase on the order of ~ 2.5x when compared to industry-standard arrays.

This work contains an overview of the manufacturing process, as well as representative data for 5-, 10-, and 20-bar arrays. Near-field and power vs. current data is presented in each case. Power densities approaching 15 kW/cm² are presented. In addition, power and wavelength are presented as a function of pulse width in order to determine the acceptable operational parameters for this type of array. In the low repetition rate Nd:YAG pumping regime, all devices are shown to operate with relatively low junction temperatures.

A discussion of future work is also presented, with a focus on extending the HDS architecture to reliable operation at 300W per bar. This will enable power densities of approximately 25 kW/cm².

Continue reading

Reliability of High-Power QCW Arrays

983x300 diodes fiber laserNorthrop Grumman Cutting Edge Optronics has developed a family of arrays for high-power QCW operation. These arrays are built using CTE-matched heat sinks and hard solder in order to maximize the reliability of the devices.

A summary of a recent life test is presented in order to quantify the reliability of QCW arrays and associated laser gain modules. A statistical analysis of the raw lifetime data is presented in order to quantify the data in such a way that is useful for laser system designers.

The life tests demonstrate the high level of reliability of these arrays in a number of operating regimes. For single-bar arrays, a MTTF of 19.8 billion shots is predicted. For four-bar samples, a MTTF of 14.6 billion shots is predicted. In addition, data representing a large pump source is analyzed and shown to have an expected lifetime of 13.5 billion shots. This corresponds to an expected operational lifetime of greater than ten thousand hours at repetition rates less than 370 Hz.

Continue reading

Next Generation High Energy Diode Pumped Laser System



                                                                                                                                                   gigashot_dpss_laserNewly published data for the next generation high energy, short pulse, Nd:YAG laser system is now available.  The GIGASHOT DPSS laser delivers 320 mJ of pulse energy in pulses that are less than 9 ns at 1064 nm. Integrated harmonic generation and wavelength separation options for 532 nm and 355 nm output are also available. This article contains specification data, beam images, beam quality data, and stability runs at 1064 nm, 532 nm and 355 nm.
Continue reading

200W @ 532nm Laser Data

200W @ 532nm Laser Data

Newly published data on CEO’s highest average power (Q-Switched @ 532 nm) laser is now available for download. This document details typical beam images, M² data, and repetition rate vs. power / pulse width data. This 200W laser is ideally suited for high-speed imaging, high-speed spectroscopy, and ultrafast amplifier pumping.


Laser Diode Construction: Golden Bullet vs. Silver Bullet

silver&goldenNorthrop Grumman – Cutting Edge Optronics (CEO) manufactures laser diode arrays based on two main types of technology, hard solder (CEO Golden Bullets) and soft solder (CEO Silver Bullets). Golden Bullets are state-of-the-art and are built using gold-tin solder and heat sinks that have the same CTE (coefficient of thermal expansion) as the laser diode bar. As a result, arrays built from Golden Bullets are extremely resistant to solder creep and other failure modes that result from thermal expansion and contraction in the array.

Continue reading

Laser Pulse Train Amplification with PowerPULSE Amplifiers

High peak power optical pulses are very desirable in industrial, scientific, and military applications.REA PowerPULSE However, maximum peak powers are limited by the damage threshold of the optical materials used and the amount of amplification available. While pulse-pumped amplifiers can achieve high gains, they are typically limited in total average power. Practical pulse trains contain pulses that are 10s of picoseconds in width, repeat every microsecond or faster, and have pulse bursts lasting 1-5ms or longer. Under these conditions a higher average power is needed to sustain the amplification of the pulse train.

Northrop Grumman Cutting Edge Optronics has developed a line of laser amplifiers that have the high gain of the pulse pumped amplifiers, and can maintain the amplifier gain for 1-5ms. This allows the amplification of long pulse trains using fewer devices, less gain material, and lower overall cost.

© 2011 Northrop Grumman Systems Corporation – All Rights Reserved

Continue reading

kW-Class, Wavelength-Stabilized Laser Diode Arrays

Numerous laser media exist with absorption peaks that are too narrow to make use of standard laser diode pump arrays with emission widths of 2-3 nm. For these absorption peaks (such as Nd:YAG at 885nm, Nd:YVO4 at 880nm, and Yb:YAG at 969nm), laser diode pump arrays with narrower emission spectra are highly beneficial.

Northrop Grumman Cutting Edge Optronics has developed a process for building high-power laser diode arrays with narrow emission spectra by adding Volume Bragg Gratings during the packaging process. These arrays emit with a spectral width of approximately 0.5nm (FWHM), and are available with output powers ranging from tens of watts to several kilowatts. Experimental data is presented in this technical note for arrays operating at up to 100W per bar (CW).

© 2011 Northrop Grumman Systems Corporation – All Rights Reserved

Continue reading
